The LT HQ2000-S is a CNC copper busbar sawing machine built around a high speed disc saw blade, giving a fast cut with a high-verticality cut face and...
The LT HQ2000-S is a CNC copper busbar sawing machine built around a high speed disc saw blade, giving a fast cut with a high-verticality cut face and no collapse at the angle. Long busbars are clamped once and the machine then switches the clamp automatically through the cutting sequence, so repeated cuts need no manual intervention. Copper busbar is held pneumatically, which is quick to clamp and easy to maintain, and the axes run on high precision ball screws with linear guides. UK busway and switchgear producers use it where cut quality and repeat lengths matter more than the total cut volume.
Test conditions: Copper busbar cutting on a high speed disc saw blade with pneumatic busbar clamping; long busbars clamped once with automatic clamp switching through the cutting sequence.
Measured values: Saw blade rotational speed 2 800 r/min; blade diameter 400 mm; X-axis maximum positioning speed 50 m/min; X-axis stroke 2 000 mm; minimum plate length 30 mm; machining range 30 × 3 – 200 × 15 mm; overall size 3 300 × 1 300 × 750 mm.
Benchmark: Disc sawing against band sawing: the disc gives a faster cut and a cut face that is close to square without a secondary facing operation, which is what removes a step from the busbar workflow.
HQ2000-S CNC Copper busbar sawing machine
Main Function:
copper/aluminum busbar sawing machine
The CNC busbar sawing machine is a new generation of CNC machining equipment developed by our company.The main function is to cut different kinds of busbars.The machine adopts high speed disc type saw blade.high cutting speed.Cutting section high verticality.No collapse angle.Is an ideal processing equipment for the bus dust industry to segment the bus bar.
Main Features:
1.This product is mainly used for the cutting process of bus bar.
2.The machine adopts high speed disc type saw blade.high cutting speed.Cutting section high verticality.No collapse angle.
3.For long busbar can clamp once.during cutting process no need manual intervention, automatic repeat switch clamp.high automatic degree.
4.The main striking head of this machine uses the hydraulic work way.With the advantages of high pressure,steady performance,high safety.
5.Copper busbar clamping adopt pneumatic clamping way,clamping fast,easy to maintain.
6.The machine uses the man-machine interface (touch screen) dialogue mode,when it is working,just need to set the relevant parameters simply.Can be convenient and quick to cut off the bus bar.With the advantages of easy operation,not with high demand for the operator.
7.The machine adopts driving mode of high precision ball screw with high precision linear guide.with the advantages of High precision, high efficiency, low energy consumption, high stability.
Tech Paramete:
Saw blade rotating speed : 2800r/ min
Saw blade diameter : 400mm
X axis maximum positioning speed :50 m/min
X axis stroke : 2000mm
The plate allows min length : 30mm
Machining range : 30 x 3-200 x 15mm
Overall size : 3300 x 1300 x 750mm
Total weight : 1300kg
